Roco 10767 Reversing Loop Module

Reversing loop module with three switching types: 1) Short-circuit switching 2) Rail detection switching (reed switch) 3) Cell switching. All three switching principles can be selected on the housing. In case 1, the short circuit is detected and the polarity is reversed. In cases 2 and 3, the polarity is detected and then switching is initiated before the short circuit occurs. This principle requires more extensive wiring. This module can also be used in analog mode. In this case, trains can only run in one direction. Technical data: Voltage up to: 22V Overload current: 5A Current: 3A Current for the module: 50mA Dimensions: 90 x 80 x 25 mm.
